DT-355 Wiring Diagram DIP Switch Settings Ceiling Mounting Product Controls 4 Square 225 Deep Junction Box with Double Gang Mudring attached Drop Ceiling Front Cover CA-1 Adapter Rear Housing Screws Sensor Flange Load Load Hot Neutral Ground Neutral Optional Keyhole slots for mounting to 4 octagonal box. DUAL TECHNOLOGY LINE VOLTAGE CEILING SENSOR DT-355 Architecturally appealing low profile appearance Operates at.
Boss V Plow Wiring Diagram Electrical Diagram Snow Plow Wiring Diagram
WattStopper DT-355 - Dual Technology Line Voltage Ceiling Sensor.
Dt 355 wiring diagram. The light level feature can be used to keep lights from turning on if the ambient light level is sufficient. Wattstoppers low profile DT-355 dual technology occupancy sensor combines the benefits of passive infrared PIR and ultrasonic technologies. Wiring Mounting Wiring Diagram Ceiling Mounting Controls Settings Product Controls DIP Switch Settings Coverage Placement Coverage Patterns Catalog Voltage Load Rating Coverage DT-355 0-800W BallastTungstenLED DT-355-U 120 VAC 5060 Hz 277 VAC 5060 Hz 347 VAC 5060 Hz 0-1200W BallastLED 0-1500W BallastLED up to 1000 ft 2 929 m.
8 fire suppression system to include two. Operation The DT-355 is line voltage and operates at 120 230 277 or 347 VAC. Refer to the wiring diagram on the next page for the following procedures.
Ad Search for Electrical diagram at MySearchExperts. Ad Search for Electrical diagram at MySearchExperts. In addition because the DT-355 can be mounted onto a variety of junction boxes the sensor has the flexibility to be used in a wide range of spaces.
Page 2 The DT-355 turns lighting systems on and off based on occupancy and ambient light levels. Wattstopper Dt 300 Wiring Diagram wiring diagram is a simplified satisfactory pictorial representation of an electrical circuit. Connect the low voltage.
Find info on MySearchExperts. Junction box DT-355 Units per power pack. WIRING DIRECTIONS Each WattStopper BZ series power pack can supply power for 5 DT-305 sensors.
Dt 200 Series Dual Technology Ceiling Wall Sensors Legrand. Connect lead wires from Power Pack to LINE circuit per appropriate WIRING DIAGRAM as follows. The sensor turns lighting on when.
Least 4 to 6 feet away from air supply vents. The sensors eliminate the need for a power pack by using line voltage wiring. DT-305 up to 3 B up to 4 BZ 45 diameter x 102 1443mm x 259mm Extends approx 36 from ceiling UL and CUL listed 5 year warranty Specifications Wiring Diagrams Coverage Pattern Ultrasonic diffusers give more comprehensive coverage.
4 ceiling occupancy sensor wiring diagram nts. Watt Stopper Wiring Diagram Wiring Schematic Diagram. The standard setting recommended for most applica-tions is both technologies to trigger on either to hold on.
Learn how to correctly wire a DT-305 Dual Technology Ceiling Sensor. The DT-355 is designed for a ceiling heights of. RED wire 24VDC from power pack to the 24V terminal on the sensor.
As a general rule each occupant should be able to clearly. Room Controller Installation Part 2 Youtube. 5 not used not used nts.
2 not used under slab conduit nts. It shows the components of the circuit as simplified shapes and the facility and signal links together with the devices. Ci 24 Passive Infrared Hvac Bas Ceiling Sensor Pir Hvac Bas.
The sensor mounts on the ceiling with a flat unobtrusive appearance and provides 360 degrees of coverage. Wattstopper Dt 300 Wiring Diagram Dt 300 Series Dual Technology Ceiling Sensors Legrand. Coverage shown is maximum and represents half-step walking motion.
3 not used nts. 120230277347V - White - UL listed - 5 Year Warranty. DT-355 Wiring Diagram DIP Switch Settings Ceiling Mounting Product Controls The technology control occupancy logic options are adjustable by user.
Mount the sensor to the ceiling. The sensors eliminate the need for a power pack by using line voltage wiring. For quick and easy installation Architecturally appealing low profile appearance.
DT-300 up to 2 B up to 3 BZ. Page 3 It is also recommended to place the sensor 4 to 6 feet away from air. Pw 100 24 Passive Infrared Low Voltage Wall Switch Sensor Legrand.
When using more sensors than this multiple power packs are required. Addition because the DT-355 can be mounted onto a variety of junction boxes the sensor has the flexibil-ity to be used in a wide range of spaces. In addition because the DT-355 can be mounted onto a variety of junction boxes the sensor has the flexibility to be used in a wide range of spaces.
Mounting above or below this range will significantly affect the. Wattstopper dt-355 line voltage dual technology ceiling sensor ground line 120vac60hz green symbol on plan - green fire suppression system wiring diagram nts. Make sure that ends of conductors are straight.
Find info on MySearchExperts. Remove 58 16 cm of insulation from each circuit conductor. Twist strands of each lead tightly and with circuit conductors push rmly into appropriate wire connector.
The sensors eliminate the need for a power pack by using line voltage wiring. Operates at 120.
